OVERVIEW
Features
Easy bolt-on installationMaintains factory ride qualityIncreased ground clearanceLevels the front with the rear of the vehicleRadius arm drop brackets allow for properly set caster. Proper caster is crucial to maintaining factory handling and driveability.
Notes
Overload spring must be removed to install this kit.Does NOT 2011-2016 F-350 models.Does NOT fit dually models.
Install Time
3 - 4 hours
Instruction
View Instruction SheetFitment
2011-2016 4WD Ford F-250 Super Duty
Tire Fitment
35x12.50R20 Factory 20 8x170 - -35x12.50R18 Factory 18 8x170 - -35x12.50R17 Factory 17 8x170 - -35x12.50R17 17x9 8x170 -12 -315/70R17 17x9 8x170 -12 -35x12.50R17 17x9 8x170 +0 -35x12.50R17 17x9 8x170 +1 -295/70R18 18x8.5 8x170 +0 -295/70R18 18x8.5 8x170 +1 -35x12.50R18 18x9 8x170 -12 -295/70R18 18x9 8x170 -12 -285/75R18 18x9 8x170 -12 -35x12.50R18 18x9 8x170 +0 -295/70R18 18x9 8x170 +0 -285/75R18 18x9 8x170 +0 -35x12.50R18 18x9 8x170 +1 -295/70R18 18x9 8x170 +1 -285/75R18 18x9 8x170 +1 -295/70R18 18x10 8x170 -25 -295/70R18 18x10 8x170 -19 -295/70R18 18x10 8x170 -18 -35x12.50R20 20x9 8x170 -12 -35x11.50R20 20x9 8x170 -12 -295/65R20 20x9 8x170 -12 -295/60R20 20x9 8x170 -12 -35x12.50R20 20x9 8x170 +0 -35x12.50R20 20x9 8x170 +1 -35x12.50R20 20x10 8x170 -25 Minor Trimming295/60R20 20x10 8x170 -25 Minor Trimming35x12.50R20 20x10 8x170 -19 Minor Trimming295/60R20 20x10 8x170 -19 Minor Trimming35x12.50R20 20x10 8x170 -18 Minor Trimming295/60R20 20x10 8x170 -18 Minor Trimming35x12.50R22 22x10 8x170 -25 Minor Trimming35x12.50R22 22x10 8x170 -19 Minor Trimming285/55R22 22x10 8x170 -19 -35x12.50R22 22x10 8x170 -18 Minor Trimming285/55R22 22x10 8x170 -18 -35x12.50R22 22x12 8x170 -44 Trimming Required
