OVERVIEW
Features
Easy bolt-on installation.Increased ground clearance.Levels the front with the rear of the vehicle.Radius arm drop brackets allow for properly set caster. Proper caster is crucial to maintaining factory handling and driveability.Fabricated blocks are stronger and offer a longer lifespan than cast blocks.
Notes
Does NOT F-350 models.Does NOT fit gas engine models.Does NOT fit dually models.A carrier-bearing drop bracket is needed for trucks equipped with a 2-piece rear driveshaft.SKU: 1197.Does NOT work on models equipped with Tremor Package.If equipped with factory top mount overload spring it will need to be removed.
Install Time
5 - 6 hours
Instruction
View Instruction SheetFitment
2017-2022 4WD Ford F-250 Super Duty
Tire Fitment
35x12.50R20 Factory 20 8x170 - -35x12.50R18 Factory 18 8x170 - -35x12.50R17 Factory 17 8x170 - -35x12.50R17 17x9 8x170 +0 Minor Trimming35x12.50R17 17x9 8x170 +1 Minor Trimming35x12.50R17 17x9 8x170 +18 Minor Trimming35x12.50R17 17x9 8x170 +20 Minor Trimming35x12.50R18 18x9 8x170 +0 Minor Trimming295/70R18 18x9 8x170 +0 -285/75R18 18x9 8x170 +0 -275/75R18 18x9 8x170 +0 -35x12.50R18 18x9 8x170 +1 Minor Trimming295/70R18 18x9 8x170 +1 -285/75R18 18x9 8x170 +1 -275/75R18 18x9 8x170 +1 -35x12.50R18 18x9 8x170 +18 Minor Trimming295/70R18 18x9 8x170 +18 -35x12.50R18 18x9 8x170 +20 Minor Trimming295/70R18 18x9 8x170 +20 -35x12.50R20 20x9 8x170 +0 Minor Trimming35x12.50R20 20x9 8x170 +1 Minor Trimming35x12.50R20 20x9 8x170 +18 Minor Trimming35x12.50R20 20x9 8x170 +20 Minor Trimming
